MILS0800-SR

L2/L3 SFF Military Switch Router

Overview

As modern military vehicles become increasingly digitised, Ethernet has become a critical backbone for enabling high-speed, reliable, and interoperable communications between onboard systems. From sensor integration to real-time data sharing, Ethernet ensures seamless connectivity across mission-critical platforms.

The MILS0800-SR switch is the entry level model of the new MILS platform series. This  compact unit provides high-performance Ethernet switching and connectivity in space-constrained military environments.

Compact in size. Powerful in performance. Designed for duty.

Key Features

  1. Entry level 8x 10/100/1000BASE-T Copper Ethernet ports
  2. Full in-house design (including networking and synchronization IP Cores) based on a reconfigurable MPSoC platform with edge computing capabilities.
  3. Simplified management and monitoring via a user-friendly HTTPS web interface or a flexible console port
  4. Sealed military grade and compact enclosure with MIL-STD-1275E power supply

Technical Specifications

  • Communication Interfaces
    • 8x 10/100/1000BASE-T Copper Ethernet ports
    • 1x 10/100/1000BASE-T Ethernet Service port
    • 2x RS-232 serial line (Miscellaneous connector)
  • Layer 2 Features
    • IEEE 802.3-2008 (Ethernet)
    • Automatic MAC address learning and aging
    • Static MAC Table
    • Port-Based Virtual LANs (VLANs):
      • Logical segmentation of network for optimal use of bandwidth
      • IEEE 802.1Q for VLAN tagging (up to 4K VLAN groups)
      • IEEE 802.1p for Class of Service (CoS) / Quality of Service (QoS)
    • IEEE 802.1AB for Link Layer Discovery Protocol (LLDP)
    • Port rate limiting
    • Storm control for flooded broadcast, multicast and unicast
    • Layer 2 multicast filtering
    • IGMP Snooping (up to 1024 multicast filters)
  • Redundancy
    • Spanning Tree Protocol:
      • IEEE 802.1D (STP)
      • IEEE 802.1w (RSTP)
      • IEEE 802.1s (MSTP)
  • Layer 3 Features
    • IPv4/IPv6 unicast and multicast routing
    • Static routing
    • Virtual Router Redundancy Protocol (VRRP)
    • DSCP ToS/QoS
    • Source/Destination NAT
    • Dynamic Routing:
      • OSPFv2, OSPFv3
      • RIPv1, RIPv2, RIPng
      • BGPv4
      • EIGRP
      • PIM-SM (IPv4 and IPv6)
    • Policy Based Routing (PBR)*
    • Proxy ARP* Supported in 2026
  • Gateway
    • Edge-computing capabilities for user defined applications (optional)
    • Support for DDS standard and MQTT protocol in KVM Virtual Machine for user application (optional)
  • Synchronization
    • NTP (Server/Client)
  • Security
    • MAC port binding & authentication for login security
    • RADIUS authentication
    • RBAC (Role Based Access Control)
    • Selective ports disabling capability
    • Unsecure protocols disabling capability
    • HTTPS for web interface
    • Secure Shell (SSH) Protocol v2 for command line interface
    • TPM 2.0 IC for identity authentication
    • Encryption / authentication & signature for firmware and bitstream
    • Secure-boot capability
  • Configuration & Management
    • HTTPS web interface
    • SSHv2 command line interface (CLI)
    • SNMP V1/V2c/V3 protocol support
    • SNMP V3 encrypted authentication and access security
    • SNMP over TLS support
    • Encrypted and digitally signed firmware / bitstream upgrades
    • Saving and restoring configuration
    • Per port statistics independent
    • Internal status monitoring and logging
    • Event notification through Syslog
    • DHCP/DHCPv6 server and relay
    • Built-in-Test capability including:
      • PBIT (Power-on BIT)
      • CBIT (Continuous BIT)
      • IBIT (Initiated BIT)
    • In-band management via any Ethernet switch port or out-of-band via Ethernet service port
    • RS-232 serial console
  • Processing
    • Xilinx UltraScale+ MPSoC device:
      • 2x 64bit ARM-Cortex-A53
      • 2x 32bit ARM-Cortex-R5F
      • 1x 16nm UltraScale+ FPGA
    • Up to 4GB DDR4 RAM memory
    • 32GB eMMC Flash memory
    • 512Mb QSPI Flash memory
  • Physical & Electrical Characteristics
    • Military certified fanless rugged design
    • Dimensions (mm): 185(W) x 160(D) x 98(H)
    • Weight: 1.9kg
    • Power Input: 28VDC
    • Power consumption: TBD
    • Connectivity via D38999 connector
  • MTBF
    • TBD hours GB@25
    • MTTR = TBD hours
  • Warranty
    • 2 years
  • Export Control
    • ITAR Free
  • Certifications

    The following certifications are expected to be achieved by the switch:

    • MIL-STD-461G: CE101, CE102, CS101, CS114, CS115, CS116, RE101, RE102, RS101, RS103
    • MIL-STD-810G: 500.5, 501.5, 502.5, 506.5, 507.5, 508.6, 509.5, 510.5, 513.6, 514.6, 516.6
    • RTCA DO-160G: Sections 4, 7, 8, 15, 16, 17, 18, 19, 20, 21, 25, 26
    • MIL-STD-1275E
    • ESD EN61000-4-2
    • IEC-60529 – IP67
    • CE Certification

    For more info, contact your sales representative.
